Abgekündigt Lenovo ThinkStation P520 Tower Workstation Intel Xeon W 2225, 32GB RAM, 512GB SSD, Win 10 Pro, NVIDIA Quadro P2200
- Intel® XEON™ W 2225 mit bis zu 4,6GHz Quad-Core-Prozessor
- Microsoft Windows 10 Professional 64 Bit
- 32GB RAM, 512GB SSD, DVD-Brenner, 9 in 1 SD Media Card Reader
- NVIDIA Quadro P2200 - 5GB, Formfaktor: Mid Tower
- USB 2.0, USB 3.1, Gigabit LAN, Seriell
Varianten:
Artikelnr.:
15512468
Herstellernr.:
30BE00HHGE
EAN:
195477837140
Technische Daten
PDF-Datenblatt| PERFORMANCE | |
| Processor |
Intel Xeon W-2225 (4C / 8T, 4.1 / 4.6GHz, 8.25MB)
|
| Processor Sockets |
1x FCLGA2066
|
| Discrete Graphics |
NVIDIA Quadro P2200 5GB
|
| Chipset |
Intel C422
|
| Memory |
2x 16GB RDIMM DDR4-2933 ECC
|
| Memory Slots |
8 DIMM sockets with 4 channels
|
| Max Memory |
Up to 512GB (with 8 x 64GB DDR4-2933 RDIMMs)
|
| M.2 SSD RAID Controller |
RAID 0/1
|
| M.2 SSD Drive |
1x 512GB SSD M.2 PCIe NVMe Opal
|
| HDD Controller |
Onboard Intel RSTe SATA
|
| Internal Disk Drive |
None
|
| PCIe SSD Adapter |
None
|
| Storage Support |
Up to 6x 3.5" SATA HDD / 2.5" SATA HDD / 2.5" SATA SSD + 9x M.2 PCIe SSD + 1x PCIe AIC SSD • 3.5" HDD up to 6TB each • 2.5" SATA HDD up to 500GB each • 2.5" SATA SSD up to 2TB each • M.2 PCIe SSD up to 2TB each • PCIe AIC SSD up to 480GB each
|
| Optical |
1x 9.0mm DVD±RW
|
| Audio Chip |
High Definition (HD) Audio, Realtek ALC662 codec
|
| Power Supply |
690W Platinum Fixed
|
| DESIGN | |
| Keyboard |
USB Traditional Keyboard, Black, German
|
| Mouse |
USB Calliope Mouse
|
| Expansion Slots |
|
| M.2 Slots |
Up to 9x M.2 SSD: • 2 via onboard slots • 4 via Quad M.2 to PCIe adapter • 3 via Single M.2 to PCIe adapters
|
| Bays |
4x 3.5" disk bays (2 standard, 2 optional)
|
| Flex Bays |
2x flex bays. Supports the following: • 2x half-height optical drives • 2x 5.25" 9.0mm optical drives • 1x 5.25" 9.0mm optical drive + 2x 3.5"/2.5" SATA SSD/HDD • 1x 3.5"/2.5" SATA SSD/HDD with Front Access Storage Enclosure • 1x flex module for the following options: Tray 1: 9.0mm optical Tray 2: 15-in-1 USB 3.1 Gen 1 reader, 2x Thunderbolt, or 4-digit diagnostic display Port 1 and 2: Front USB 3.1 Gen 1 Type-C or eSATA • 2x M.2 SSD with 2x Front Removable Drive Enclosures
|
| Dimensions (WxDxH) |
165 x 460 x 440 mm (6.5 x 18.1 x 17.3 inches, with feet)
|
| Weight |
24 kg (52.91 lbs, maximum configuration)
|
| CONNECTIVITY | |
| Onboard Ethernet |
1x GbE RJ-45
|
| Optional Ethernet |
None
|
| WLAN + Bluetooth |
None
|
| Card Reader |
SD Reader
|
| Front Ports |
|
| Optional Front Ports |
None
|
| Rear Ports |
|
| Optional Rear Ports |
1x Serial
|
| SECURITY & PRIVACY | |
| Security Chip |
Discrete TPM 1.2, TCG certified
|
| Physical Locks |
|
| Cover Lock |
Lock Kit with Common Key
|
| Chassis Intrusion Switch |
None
|
| MANAGEABILITY | |
| System Management |
Intel vPro with AMT 11, DASH
|
| Diagnostic |
None
|
| SERVICE | |
| Base Warranty |
3-year, Onsite
|
| Included Upgrade |
None
|
| CERTIFICATIONS | |
| Green Certifications |
|
| ISV Certifications |
Please visit www.thinkworkstations.com/isv-certifications/
|
| SOFTWARE | |
| Operating System |
Windows 10 Pro 64 for Workstations, German
|
| Bundled Software |
None
|
